Is it possible to create twisted die walls with Extruded Products Builder?

Hello,

Usually Die walls follow one curve with top and bottom plates being  parallel to each other and  maybe offset of each other, with equal length studs.

I have a situation were Top and Bottom plates are the same but they are slightly rotated of each other. So the Die wall is twisted and as a result studs slightly vary in length. Plates are still in parallel planes.

Is it possible to model this with EPB?


This is a top view where you can see the slight rotation between the Top and Bottom plate.
